Select Clear Message to clear your message and continue using your meter. Replace your ink cartridge. See Replacing your ink tank on the DM100i-DM225. If you need ink, order a genuine Pitney Bowes replacement ink cartridge: Use the Contact Us options below if you need further assistance. Have your model and serial number ready.
Pitney Bowes K700. K7M0 User Manual. Download 4.83 Mb. Digital Postage Meter. Install Guide. US English Version. The Communication Device enables your meter to connect to Pitney Bowes via the Internet to access postage downloads. It’s packaged in its own cardboard box. Using you Pitney Bowes user name and password.

Pitney Bowes P700 Download
Pitney Bowes P700 Manual

Mailstation, mailstation2, DM125-DM475 URL, IP Address User Guide 'Meter Not Detected' with PC Meter Connect. Setting up a wireless (WiFi) connection with a SmartLink device on the mailstation series and DM100i-DM475. Installing PC Meter Connect.

Choose an appropriate location for the meter

Position the meter close to both a power and phone outlet. The meter must be plugged into a power outlet at all times.

Some commercial phone systems use digital lines that may damage the meter. Like the meter, most fax machines, credit card readers and modems also require analog lines. The meter can share a line with these devices. When in doubt, ask the person responsible for your phone system.

You transfer funds to the meter as part of the setup process.

¥At the prompt, INSERT FORM FOR RECEIPT, insert an envelope or postage meter tape sheet to print receipt.

¥Press the C (Clear) key to return the postage to $0.00.

Lock
3	Refil
2	Postage
1	6
5	No
e	No
eDat	4	9	Yes
Advanc	8		Yes
Funds/Pieces	7	.	refill
Ads	7	.
0
Setup	C
receipt

Amount remaining in	Amount moved from
		Account #: 12345678
POSTAGE BY PHONE¨	Date: 06/10/01	Meter# : 87654321	POSTAGE BY PHONE¨
account at Pitney Bowes	Refills Left:	account into meter.
	Refill Amount: $
after transfer.	Account Balance: $

12After setting up the Meter

Use the Quick Reference Guide under the meter for How To's on:

- Adjusting the Display Contrast

- Changing the Date and Time - Locking the Meter

- Printing Postage

- Replacing Ink Cartridge

- Using the Meter Ads/Messages

Quick Reference

Guide

Troubleshooting

Black square lines display

¥ Unplug the power cord from the wall outlet.

¥ Remove the batteries. Wait 15 seconds; then plug in the meter. Reinstall batteries.

¥ Reset date and time using Setup key.

Display is blank

Ensure the power supply is plugged in.

Examine pins on connector to see if any are bent or broken.

REFILL FAILED - CHECK ACCT#

Pitney Bowes P700 Download

The account number is noted in the top right hand corner of this document.

Press the Setup key repeatedly until CHANGE POSTAGE ACCOUNT NUMBER? displays; press yes.

NO DIAL TONE

Ensure phone cord is plugged in both meter and wall. If it is, the telephone line may not be an analog line. Try using a fax machine line.

CANNOT REACH DATA CENTER

Check the number you have entered as a dialing prefix. Some phone systems require a pause between dialing the prefix and the number. Clear any error messages by pressing the C (Clear) key.

Use the decimal (.) key to enter a pause after the prefix.

Press the Setup key repeatedly until CHG PB PHONE #? displays; press yes. Key in a prefix, if needed, followed by 1-800-848-3764 (ex:9.1800 848 3764)

PRINTER JAMMED

The yellow shipping blocks have not been removed. Lift the cover and remove the two shipping blocks.

Still have questions?

Visit our Web Site at: www.pitneyworks.com/metersupport to view FAQ's and Operators Guide or call us at 1-800-468-8454.

1read this first..

Pitney Bowes P700 Manual

4Unpack the Meter

Remove all contents from the shipping box and locate items shown.

Do not attach the power cord to the meter until Step 7.

A
A
A	AAA
AAA	AAA
Batteries		power	phone	ink
cord	cord	cartridge

E700

Postage Meter

Quick Install Guide

ck
Lo
3	efil
2	eR
	stag
1	Po
	6
te		5	No
	4
Da
e		9
nc
va		es
Ad			8
Y
s	nter
Ad		7	.
0
tup		C
Se
es
iec
s/P
nd
Fu

www.pitneyworks.com/metersupport

Example of good test print - no missing horizontal lines or breaks in the vertical lines.

5Install Ink Cartridge

¥ Lift the meter cover and remove the yellow plastic stop.

¥ Open the blue cartridge cover by squeezing the side tabs and pivoting the cover back.

¥ Remove the second yellow block from the Ink Cartridge holder.

¥ Pull the tape off the Ink Cartridge and place Ink Cartridge into meter.

¥ Snap blue cartridge cover in place. Farmall 560 manual download.

! Use only Pitney Bowes ink. All other inks could damage the meter.

6	Install Batteries
	¥ Remove the blue battery cover behind the printer by lifting up
	on the two tabs.
	¥ Install all three batteries with the positive terminal (+) facing to
	the right. Replace the battery cover and close the meter
cover.

7Connect Power

¥ Connect the power cord to the meter with the arrow facing up.

¥ Plug the other end of the cord into an outlet that is not controlled by a switch or surge protector; there is no on/off switch on your meter.

Your Postage By Phone¨ Account Number:

9Print Test

¥ At the prompt, INSERT FORM FOR PRINT TEST, insert a postage tape sheet or any envelope into the meter. Insert the envelope or tape sheet face up all the way into the slot and slide it to the right.

¥ At prompt PERFORM PRINTER MAINTENANCE press the No key if print test is okay and Yes/Enter if the print test fails.

10Initializing Setup

¥ Press the No key to all prompts except the following:

¥ At the prompt, INSPECTION REQUIRED, press C (Clear) key. Meter will display the date and the postage amount, press

Setup key.

¥ At the prompt, CHANGE DATE?, press Yes/Enter key and enter the current date (mm/dd/yy), press the Enter key when finished.

¥ At the prompt, CHANGE TIME?, press Yes/Enter key and enter in the current time in HH:MM format. Press the Yes/Enter key when finished. You will be prompted for the A.M. or P.M. selection.

¥ If your phone system requires a dailing prefix such as Ò9Ó to obtain an outside line press the Yes/Enter key. Enter the dailing prefix plus the POSTAGE BY PHONE¨ number. (Example: 9.1.800.848.3764) If your system requires a pause between dailing the prefix and the number enter a decimal (.) for the pause.

¥ At the prompt, PB PHONE#?, the POSTAGE BY PHONE¨ DATA CENTER phone should be displayed. If you do not need to modify the phone number to include a dialing prefix press the No key.

Note: Some phone systems require a pause between dialing the prefix and the number.

¥At the prompt, CHANGE POSTAGE ACCOUNT#?, press the

Yes/Enter key.

¥Enter your account number

press the Yes/Enter key when finished.

¥At the prompt, INSPECTION REQUIRED? press the C (Clear) key.

11Add Postage to the Meter - Postage Refill

¥ Connect one end of the phone cord supplied to meter and plug the other end into a phone jack.

8Prime Printhead

¥ At the prompt, CANNOT FIND ZIP-REFILL REQUIRED, press

Yes/Enter key.

¥ At the prompt, IMPORTANT-IS INK INSTALLED?, press Yes/Enter key. This will begin the ink loading process.

The meter displays the message PLEASE WAIT while it performs the maintenance process. This takes about three minutes.

No key
eDate	Yes key
Advanc
Ads	.	Clear key
Fun		Clear key
Setup
s
ds/Piece

Setup key

phone cord

¥Press the Refill key.

¥Enter the amount of postage you wish to add to the meter in whole dollar amount. Press the Yes/Enter key. The meter automatically dials the data center and transfers funds to the meter.

If you receive the CANNOT REACH DATA CENTER OR NO DIAL TONE, see 'Troubleshooting' on the back page. (Call waiting and voice mail beeps can disrupt funds transfers.)

(Step11 continues on back..)
